#1011163039 | Mfg #500 | Clinical Laboratory

Automated ELISA Processing System The Bolt™

ANALYZER, BOLT ELISA 1UL-300ULD/S
Automated ELISA Processing System The Bolt™

The Bolt is a single compact machine that serves as all of the tools for processing an ELISA assay (pipette, washer, incubator, shaker, reader)

Product Specifications

MSFH #
1011163039
Manufacturer #
Gold Standard Diagnostics Corp, The Bolt™, 500, Unknown
Brand
Automated ELISA Processing System
Manufacturer
Built-in LED Spectrophotometer
Country of Origin
Linear Shaker / Incubator
Application
48.3 X 53.3 X 55.8 cm
Contents 1
100 to 265V
Dimensions
50/60 Hz
Power Source
120W Max
Sample Capacity
96 Postion Sample Capacity
Test Name
ELISA
UNSPSC Code
41115819
User Interface
MS Windows Graphical User Interface / Windows 7 or Above
Weight
59-1/2 lbs.

Description

Open, fully customizable architecture

Independent well tracking and timing

2 wash bottle positions

Spectrophotometer

9 custom reagent positions (22 - 35 mm diameter bottles accepted)

Accepts standard 12, 13, 16 mm diameter, up to 100 mm tall (custom racks available)

High precision micro-syringe

1 µL to 300 µL aspiration/dispense volume

LIS integration: Bi-directional, RS232, USB, TCP/IP

Fully open and highly configurable test designer; custom output reports
